Forefront of packaging excellence with BENZ Packaging's Co-Extruded Laminate Pouches. These cutting-edge pouches represent a synergy of advanced technology and superior materials, offering a packaging solution that goes beyond conventional standards. Our Co-Extruded Laminate Pouches are not just technically advanced; they are visually appealing too. The high-resolution printing capabilities ensure that your branding and product information are presented with exceptional clarity, contributing to a professional and eye-catching presentation.
  • More Information
  • Technical Specifications

Features

  • Excellent machinability
  • High heat seal strength
  • Good optical properties
  • Seals at low temperature, hence broader heat seal temperature range
  • Low COF throughout printing & laminating process

Recyclable

Technical Specifications
Property Ref. Units Astm#/Test Method HST-1 (LCF) T095
Physical Data
Average Thickness micron
gauge
mils		 D-374-C 15
59.06
0.59		 17
66.92
0.67 		18
70.87
0.71		 20
78.74
0.79 		25
98.42
0.98		 30
118.11
1.18		 35
137.80
1.38 		40
157.48
1.57
Thickness Variation %(+) 3
Density g/cc 0.905
Average Substance g/m2 13.58 15.38 16.29 18.1 22.63 27.15 31.68 36.2
Wettability (min.) dynes/cm D-2578 38
Kinetic COF UT-UT D-1894 0.2-0.3
Yield m2/Kg D-432 73.66 65.01 61.39 55.24 44.20 36.83 31.57 27.62
Optical Data
Gloss (45") gardner D-2457 88-92 86-90
Haze % D-1003 1.5-2.5 1.7-2.7
Mechanical Data
Tensile Strength MD
TD		 kg/cm2 D-882 1200 - 1500
2400-2800
Elongation MD
TD		 % D-882 150-200
30-80
Thermal Data
Shrinkage
(120 °C, 5 min.)		 MD
TD		 % D-1204 2.5-4.5
0.5-2.5
Seal Initiation Temp °C CTM 95
Heat Seal Strength g/25 mm CTM 350 400 400 450 500 525 550 575
Barrier Data
MVTR (38°C, 90%RH) g/m2/day F-1249 8 7 7 6 4.5 4 3.5 3
