benz packaging solutions
BENZ Foil Laminates Pouches feature a meticulously engineered multi-layer structure that includes a foil layer. This design provides an exceptional barrier against moisture, oxygen, UV rays, and other environmental factors, ensuring the integrity and freshness of your products, The pouches are equipped with advanced heat-sealing capabilities, guaranteeing a secure and tamper-evident closure. This feature not only enhances product protection but also extends shelf life, making our pouches an ideal choice for a variety of applications.
  • More Information
  • Technical Specifications

Features

  • Provides high bond strength
  • High level of heat and chemical resistance.
  • High initial shear strength that helps mitigate laminate defects.

Recyclable

Technical Specifications
Coating Weight 1.25-3.5 lbs/ream
Carrier Ethyl Acetate
Chemistry Polyester urethane
Color Clear Amber Liquid
Density 9.2 lbs/gallon
Mix Ratio 100:8.8 for Adcote 577B, 100:5.6 for Adcote 577C
Recommended Diluent Ethyl Acetate, Methyl Ethyl Ketone
Drying Web Temperature 150-180 °F
Key Performance Benefits high bond strength and a high level of heat and chemical resistance, high initial shear strength
Shelf Life 360 days
Applied Solids 30-45 %
Supplied Solids 75%
Solvent Ethyl Acetate
Thinner Ethyl Acetate, Methyl Ethyl Ketone
Cure Time 3-5 days @ 70 °F
Mixed Viscosity 2,300 cPs
Nip Temperature 150-220 °F
Nominal Application Temperature Room Temperatur
Post Process Time 4-8 hours @ 70 °F
Pot Life > 8 hours
Substrates Aluminum Foil, Polyester, Polyolefin, Coextruded Films
Viscosity 2,500 cps
